Karta produktu
DP1010.11.0010
DR!VE+
tarcza hamulcowa
DP1010.11.0010
TARCZA HAM. PRZÓD VAG 239X10
Kod GTU: 07
Cena
Dostępność
Łódź 0
Pabianice 0
Milionowa 0
M2 do 17.50 2dni
Parametry
| Felga, liczba otworów | 4 |
| Strona zabudowy | Oś przednia |
| Wysokość [mm] | 38,6 |
| Typ tarczy hamulcowej | pełny |
| Grubość tarczy hamulcowej [mm] | 9,9 |
| Minimalna grubość [mm] | 8 |
| średnica zewnętrzna [mm] | 238,8 |
| Liczba otworów | 1 |
| Średnica otworu centrującego [mm] | 65 |
Numery OEM
AUDI: 811 615 301, 811 615 301 B, 823 615 301
SEAT: 811 615 301, 823 615 301
SKODA: 811 615 301
VW: 811 615 301, 811 615 301 B, 823 615 301
SEAT: 811 615 301, 823 615 301
SKODA: 811 615 301
VW: 811 615 301, 811 615 301 B, 823 615 301
Odpowiedniki
A.B.S.: 08.2631.34, 15703
A.P.: 16400E
ABEX: W0220
ACDelco: AC2036D
AKRON-MALO: 1110594
AP: 16400 E
APEC: DSK137
ASHIKA: 60-00-0937, 60-00-0937C
ATE: 24.0110-0151.1, 24.0310-0151.1, 24111001511, 410151
BENDIX: 333094, 561087B, 561087BC
BLUE PRINT: ADV184386
BORG & BECK: BBD4180
BOSCH: 0 986 478 010, 0 986 479 824, 0 986 BB4 363, 986478010, F 026 A01 091
BRADI: 1.5804.1.4
BRAKE ENGINEERING: DI826313
BRAXIS: AE0093
BRECO: BS 7273
BREMBO: 08.2631.30, 08.2631.34
CAR: 142705, HPD705
CHAMPION: 561087CH
COMLINE: ADC1401, AND6692
DBA Australia: DBA242
DELPHI: BG2117
DENCKERMANN: B130001
DON: PCD12212
EUROBRAKE: 5815204704, 5815314704
EUROREPAR: 1618867180
FAG: BS1010
FEBI BILSTEIN: 02122
FERODO: DDF042, DDF0421, DDF042C, DDF042C1, DRF042, DRF042S
FIRST LINE: FBD116
FREMAX: BD-3325
FTE: BS1010, BS1010B
GALFER: B1.G210-0151.1
GIRLING: 6015183
GRAF: DF2854
HELLA: 8DD 355 100-041, 8DD 355 100-051
HELLA PAGID: 8DD 355 100-051
ICER: 78BD3325-2
JAPANPARTS: DI-0937, DI-0937C
JAPKO: 600937, 600937C
JURID: 561087J, 561087JC
KAWE: 6086 00
KLAXCAR FRANCE: 25084z
LEMFORDER: 10116 03
LPR: A1011P
MAGNETI MARELLI: 353615804140, 360704005100, 361302040197, 431602040660
MANDO: MBC035314
MAPCO: 15768
MASTER-SPORT GERMANY: 201001510, 24011001511-PCS-MS, 24011001511-SET-MS
MAXGEAR: 19-0759, 19-0759MAX, 19-0759SPORT
METELLI: 230054
METZGER: 16400E, 6110060
MEYLE: 115 521 1005, 1155211005PD
MGA: D854
MINTEX: MDC247, MDK0113, MDK0178
MJ ALLEN AUTOMOTIVE: NBD008
MOTAQUIP: LVBD1412Z
NK: 204704, 314704
OBTEC A/S: 421036, 815421036
Omnicraft: 2143191
OPTIMAL: BS-0860, BS-0860C
PAGID: 53901, 53901PRO
PEX: 140613, 140613N
PILENGA: 5151
QH Benelux: 57115
QUARO: QD4790
QUINTON HAZELL: 817102, 817103, BDC1010, BSF1010
RAICAM: RD00845
REMSA: 608600, 817102, 817103
REMY: RAD1252C
RIDEX: 82B0693
ROADHOUSE: 6086.00, 817102, 817103
ROULUNDS RUBBER: D2036
SASIC: 9004217J
sbs: 1815204704, 1815314704
SEBRO: 7115
STELLOX: 6020-4704K-SX, 6020-4704-SX
ST-TEMPLIN: 0311010010, 0311010015
SWAG: 30 90 2122
Technika: 755138
TEXTAR: 92009300, 92009303, 98200009301
TOMEX BRAKES: TX 70-88
TOPRAN: 104 164
TRISCAN: 812010137, 8120 10137C
TRUSTING: DF004
TRW: DF1518
VAICO: V10-40003
VALEO: 186017, 186249
WAGNER: WGR0042-1
WOKING: D6086.00, P608600
ZIMMERMANN: 6001050, 600105000, 600.1050.20, 600105050, 600.1050.52
A.P.: 16400E
ABEX: W0220
ACDelco: AC2036D
AKRON-MALO: 1110594
AP: 16400 E
APEC: DSK137
ASHIKA: 60-00-0937, 60-00-0937C
ATE: 24.0110-0151.1, 24.0310-0151.1, 24111001511, 410151
BENDIX: 333094, 561087B, 561087BC
BLUE PRINT: ADV184386
BORG & BECK: BBD4180
BOSCH: 0 986 478 010, 0 986 479 824, 0 986 BB4 363, 986478010, F 026 A01 091
BRADI: 1.5804.1.4
BRAKE ENGINEERING: DI826313
BRAXIS: AE0093
BRECO: BS 7273
BREMBO: 08.2631.30, 08.2631.34
CAR: 142705, HPD705
CHAMPION: 561087CH
COMLINE: ADC1401, AND6692
DBA Australia: DBA242
DELPHI: BG2117
DENCKERMANN: B130001
DON: PCD12212
EUROBRAKE: 5815204704, 5815314704
EUROREPAR: 1618867180
FAG: BS1010
FEBI BILSTEIN: 02122
FERODO: DDF042, DDF0421, DDF042C, DDF042C1, DRF042, DRF042S
FIRST LINE: FBD116
FREMAX: BD-3325
FTE: BS1010, BS1010B
GALFER: B1.G210-0151.1
GIRLING: 6015183
GRAF: DF2854
HELLA: 8DD 355 100-041, 8DD 355 100-051
HELLA PAGID: 8DD 355 100-051
ICER: 78BD3325-2
JAPANPARTS: DI-0937, DI-0937C
JAPKO: 600937, 600937C
JURID: 561087J, 561087JC
KAWE: 6086 00
KLAXCAR FRANCE: 25084z
LEMFORDER: 10116 03
LPR: A1011P
MAGNETI MARELLI: 353615804140, 360704005100, 361302040197, 431602040660
MANDO: MBC035314
MAPCO: 15768
MASTER-SPORT GERMANY: 201001510, 24011001511-PCS-MS, 24011001511-SET-MS
MAXGEAR: 19-0759, 19-0759MAX, 19-0759SPORT
METELLI: 230054
METZGER: 16400E, 6110060
MEYLE: 115 521 1005, 1155211005PD
MGA: D854
MINTEX: MDC247, MDK0113, MDK0178
MJ ALLEN AUTOMOTIVE: NBD008
MOTAQUIP: LVBD1412Z
NK: 204704, 314704
OBTEC A/S: 421036, 815421036
Omnicraft: 2143191
OPTIMAL: BS-0860, BS-0860C
PAGID: 53901, 53901PRO
PEX: 140613, 140613N
PILENGA: 5151
QH Benelux: 57115
QUARO: QD4790
QUINTON HAZELL: 817102, 817103, BDC1010, BSF1010
RAICAM: RD00845
REMSA: 608600, 817102, 817103
REMY: RAD1252C
RIDEX: 82B0693
ROADHOUSE: 6086.00, 817102, 817103
ROULUNDS RUBBER: D2036
SASIC: 9004217J
sbs: 1815204704, 1815314704
SEBRO: 7115
STELLOX: 6020-4704K-SX, 6020-4704-SX
ST-TEMPLIN: 0311010010, 0311010015
SWAG: 30 90 2122
Technika: 755138
TEXTAR: 92009300, 92009303, 98200009301
TOMEX BRAKES: TX 70-88
TOPRAN: 104 164
TRISCAN: 812010137, 8120 10137C
TRUSTING: DF004
TRW: DF1518
VAICO: V10-40003
VALEO: 186017, 186249
WAGNER: WGR0042-1
WOKING: D6086.00, P608600
ZIMMERMANN: 6001050, 600105000, 600.1050.20, 600105050, 600.1050.52
Samochody osobowe
AUDI: 100 C1 sedan (801, 803, 805, 807, 811, 813, F104) (1968-11 » 1976-07), 80 B1 sedan (80, 82) (1972-05 » 1978-07), 80 B2 sedan (811, 813, 814, 819, 853) (1978-08 » 1987-03)
SEAT: CORDOBA (6K1, 6K2) (1993-02 » 2002-12), CORDOBA Vario (6K5) (1996-07 » 2002-12), IBIZA II (6K1) (1993-03 » 2002-05)
VW: DERBY (86C, 80) (1981-08 » 1984-12), GOLF I (17) (1974-04 » 1985-12), GOLF II (19E, 1G1) (1983-08 » 1992-12), GOLF II Van (19E, 1G1) (1983-08 » 1991-07), JETTA I (16) (1978-08 » 1987-12), JETTA II (19E, 1G2, 165) (1983-08 » 1992-12), PASSAT B1 (32) (1973-05 » 1981-07), PASSAT B1 Variant (33) (1973-05 » 1981-10), PASSAT B2 (32B) (1979-09 » 1989-07), POLO CLASSIC (86C, 80) (1985-01 » 1994-09), POLO coupe (86C, 80) (1981-10 » 1994-09), POLO Furgon/hatchback (86CF) (1992-08 » 1994-07), POLO II (86C, 80) (1981-10 » 1994-09), POLO III CLASSIC (6V2) (1995-01 » 2009-11), POLO Variant (6V5) (1997-04 » 2001-09), SANTANA (32B) (1981-08 » 1985-12), SCIROCCO (53) (1974-02 » 1980-07), SCIROCCO (53B) (1980-08 » 1992-07)
SEAT: CORDOBA (6K1, 6K2) (1993-02 » 2002-12), CORDOBA Vario (6K5) (1996-07 » 2002-12), IBIZA II (6K1) (1993-03 » 2002-05)
VW: DERBY (86C, 80) (1981-08 » 1984-12), GOLF I (17) (1974-04 » 1985-12), GOLF II (19E, 1G1) (1983-08 » 1992-12), GOLF II Van (19E, 1G1) (1983-08 » 1991-07), JETTA I (16) (1978-08 » 1987-12), JETTA II (19E, 1G2, 165) (1983-08 » 1992-12), PASSAT B1 (32) (1973-05 » 1981-07), PASSAT B1 Variant (33) (1973-05 » 1981-10), PASSAT B2 (32B) (1979-09 » 1989-07), POLO CLASSIC (86C, 80) (1985-01 » 1994-09), POLO coupe (86C, 80) (1981-10 » 1994-09), POLO Furgon/hatchback (86CF) (1992-08 » 1994-07), POLO II (86C, 80) (1981-10 » 1994-09), POLO III CLASSIC (6V2) (1995-01 » 2009-11), POLO Variant (6V5) (1997-04 » 2001-09), SANTANA (32B) (1981-08 » 1985-12), SCIROCCO (53) (1974-02 » 1980-07), SCIROCCO (53B) (1980-08 » 1992-07)
