Karta produktu


2PF 009 001-521

HELLA

światła pozycyjne

BHS 2PF009001521

Lampa

Kod GTU: brak


Dostępność

Łódź 0

Pabianice 0

Milionowa 0

Do 10.10-na dziś 14.00

M3 do 18.20 jutro

M2 do 17.50 2dni

M11 do 16.00 jutro

M1 do 17.50 jutro


Parametry

Sposób montażu Zabudowa
Sposób montażu przykręcany
Projekt lampy LED
Rodzaj lampy LED
Napięcie [V] 24
Wysokość [mm] 42
Szerokość [mm] 66
Długość [mm] 66
Funkcja lampy ze światłem pozycyjnym (LED)
Liczba funkcji świateł 1
Rodzaj rejestracji Z aprobatą ECE
Liczba diod LED 12
Kolor obudowy czarny
Kolor szkła reflektora przezroczysty
Artykuł uzupełniający / informacja uzupełniająca 2 bez śruby
Ilość 1
Strona zabudowy Przód pojazdu
Montaż/demontaż koniecznie do wykonania przez fachowców!

Kody EAN

Kody użytkowe

Informacje producenta

Regarding single or double function lamps with LEDs withoutflasher functionIn connection with these low powers, which arevery different from bulb versions, there can beproblems during operation on various traction vehiclesbecause further lighting functions are detectedby some traction vehicles. This is a vehiclecomfort function which is not required by legislation anddoes not release drivers from their obligationto see for themselves that the lighting equipmentis working.Here, too, faulty diagnoses can be a result of the lowerpower levels involved (instrument panel in the driver cabindicates a bulb failure although the functionis working).The functional ability of these light failure checks canonly be established by the vehicle manufacturer.Operation of the light with alternating current or pulseddirect current is not permitted!The individual light functions may only be operated with avehicle fuse of max. 3A.In the case of onboard current limitation with the valuesspecified above by the onboard control unitan additional fuse for the lamp is not required.

Numery OEM

DAF: 888550
HIGER: 37BUH-01120
IVECO: 5801538363, E5801538363
LIEBHERR: 13135074
ROSENBAUER: 543349
TOYOTA: 0050211
VOLVO: 22273410
YUTONG: 4114-00133

Odpowiedniki
